A2502带锁扣系列东莞伟昌电子定制连接器工厂批发供应现货价格优惠免费索样品

线对板电源连接器

优势：磷铜端子可压接最大外径1.9mm规格线材，镀锡端子保证了更好导电性；胶壳PA66白色可定制环保无卤；针座PA耐温塑胶，侧面带锁扣接插件Wafer保证产品抗震动性,可定制打k脚针座。

合高：直针/弯针——8.10mm、4.2mm。

应用：空调、洗衣机、智能家居、无人驾驶飞机、打印机接头、游戏机接插件、电动工具连接器、工业自动化设备、电机电源、液晶显示器、机械键盘鼠标KEY-BOARD。

EH series wire-to-board connectors were designed to meet the demand for the high-density connection of internal wires to printed circuit boards. The small size, high reliability, and multiple position counts make the EH series a solution for many wire-to-board interconnect needs.

EH series is rated at 3 A AC/DC using 22 AWG wire, rated at 250 V AC/DC and has a temperature range of -25°C to +85°C. EH series connectors are available in 2 to 15 circuits and contact options allowing the use of 22 AWG to 32 AWG wire. These 2.5 mm pitch connectors are only 8.1 mm in height after mounting to the PCB and 3.8 mm in width.

Dual-terminated wire jumper assemblies are available in 2”, 4”, 6”, 8”, 10”, and 12” lengths.

东莞伟昌电子科技成立于2014年，注册资金1000万，位于交通便利的东莞石碣，邻近深圳、广州、惠州。

公司注塑、冲压、自动组装、端子线束等部门均严格按照ISO14001目标质量管理体系生产，主要致力于环保无卤、UL安规High temperature resistant connector、Wire to Board‍ Connectors、Board to Board Connectors、Wire to Wire connectors‍、Isulation Displacement Connectors、Pin header/Female header/Sata、FPCconnectors、FFC Connectors‍、Adaptor Board-In Connectors‍、Chain Terminal/Splices/Soldless、Terminals/Solderless Splices、Automotive connectors、Waterproof Connectors、Power Connectors、LED Connectors、LVDS Connectors、Wiring-harness‍、PC Power Cable、Ribbon Cable Connectors、SATA Cable、RF Solutions、Automotive cables、Shunt Wires及Odm/Oem connectors模具的研发、设计、生产与销售Cvilux Connectors、JWT Connectors。

产品主要替代TE‍、AMPHENOL、KET、YAZAKI、DELPHI、MOLEX、JAE、JST、HIROSE、PANASONIC、CVILUX、FCI、FOXCONN、UJU、JAM、STOCKO、SEIKO、HARWIN、KYOCERA、KEL、SAMTEC。

伟昌连接器产品广泛应用于平板电脑、笔记本、游戏机、微型投影仪、监控摄像头、智能家居、智能安防、智能穿戴、TV-Box机顶盒、LED照明电源、广告显示、DVD播放机、打印机、复印件、扫描仪、网络路由器、医疗便携式诊断、医疗监控、血液分析仪、汽车车机导航、行车记录仪、GPS全球定位系统、智能水表电表气表、变压器、工业自动化、伺服器、蓝牙模组、电源模块、背光模组、摄像头模组等。

产品环保及安全规范符合ROHS2.0、无卤、REACH及UL‍安规等……

现主要合作伙伴有HUAWEI、TOSHIBA、LOGITECH、HP、FOXCONN、AOC、PRIMAX、BYD、HSAE、CJT等……
